Hex Coupling 1/2" NPT Female x 1/2" NPT Female
Maximum cold working pressure 15,000 psi / 1.000 bar
Stainless Steel AISI 316

Hex Coupling 1/4" NPT Female x 1/4" NPT Female
Maximum cold working pressure 15,000 psi / 1.000 bar
Stainless Steel AISI 316

Pressure Indication Gauge for CJ-175-60 Pump or Hand Pump HP-500-01

Pressure Relief Valve Assembly - High Pressure - 10 KPSI

Pressure Connection : 1/2"BSP, 60 degrees swivel connection with o-ring
Outlet Connection : 1/4" NPT Female

Pressure Range ( Pink Spring ) :
- 5,000 - 10,000 PSI
- 345 - 690 bar

Maximum cold working pressure Relief Valve Body : 15,000 psi / 1.000 bar
Material Relief Valve Body : Stainless Steel AISI 316
Material Seal - Relief Valve : FKM
Material Adapter : Stainless Steel AISI 316
Material Seal - Adapter : NBR

Spiral Suction Hose with a maximum cold working pressure of 16 bar.
Minimum burst pressure: 64 bar ( safety factor 4:1 )
Total length 2,5 meter.

Stainless Steel AISI 316 GEKA Fittings
GEKA Seal: FKM

0-400 Bar Pressure Gauge
Ø150mm Stainless Steel Case with Safety Glass
Dual scale dial bar/psi
+/-1% accuracy of full scale
Bottom Connection: 1/2" BSP acc. EN 837
Wetted parts Stainless Steel AISI 316
Adjustable pointer
Not filled but fillable with glycerin
With blow-out
Every pressure gauge has its own unique serial number

Available with calibration certificate

Ø 9" Chart Recorder
0-400 Bar
1 Revolution in 24 Hour
+/-1% accuracy of full scale
1/2" BSP acc. EN 837 Connection
Wetted parts Stainless Steel AISI 316
Mechanical Spring Wound Clock
Including violet felt pen
A new recorder comes with 100 Charts
Chart number: 1750-400-24

Available with calibration certificate

Click here to download the manual

Bleed Hose with a maximum cold working pressure of 10 bar.
Minimum burst pressure: 25 bar ( safety factor 2,5:1 )
Total length 2,5 meter.
1/2"Female Camlock Fittings (DN15)

Material Camlock Fitting : Stainless Steel AISI 316
Camlock Seal : NBR

Double Nipple 1/2" NPT Male
Maximum cold working pressure 15,000 psi / 1.000 bar
Stainless Steel AISI 316

Double Nipple 1/2" NPT Male - Extended - 100mm
Total Length = 100 mm
Maximum cold working pressure 10,000 psi / 700 bar
Stainless Steel AISI 316
