0-6 Bar Pressure Gauge
Ø100mm Stainless Steel Case with Safety Glass
Dual scale dial bar/psi
+/-1% accuracy of full scale
Bottom Connection: 1/2" BSP acc. EN 837
Wetted parts Stainless Steel AISI 316
Adjustable pointer
Not filled but fillable with glycerin
With blow-out
Every pressure gauge has its own unique serial number

Available with calibration certificate

Ø 9" Chart Recorder
0-6 Bar
1 Revolution in 24 Hour
+/-1% accuracy of full scale
Connection: 1/2" BSP acc. EN 837
Wetted parts Stainless Steel AISI 316
Mechanical Spring Wound Clock
Including violet felt pen
A new recorder comes with 100 charts
Chart number: 1750-6-1

Available with calibration certificate

Click here to download the manual

1/2" NPT Ball Valve - female x female
Maximum cold working pressure: 10,000 psi / 700 bar
Stainless Steel AISI 316

Adapter 1/2" NPT male x 1/2"BSP male, 60 degree cone
Maximum cold working pressure 15,000 psi / 1.000 bar
Stainless Steel AISI 316

- Can be used to connect our Light Weight High Pressure Hose to a 1/2" NPT female connection.

Thermoplastic High Pressure Hose with a maximum cold working pressure of 10,000psi / 700 bar.
Minimum burst pressure: 40,000 psi ( safety factor 4:1 )
Total length 5 meter.
Stainless Steel AISI 316 Fittings
1/2"BSP, 60 degrees swivel connection with o-ring

The o-ring enables you to hand tighten the connecting and be leek free till maximum working pressure.

Jerrycan 20 Liters ( empty )

To bring water to the job to fill the tank and keep everything portable ( 20 KG ).

Capacity : 20 Liters
Material : HD-PE
Height : 40 cm
Width : 30 cm
Depth : 24 cm

Manifold
Maximum cold working pressure 10,000 psi / 700 bar
7 x 1/2" NPT female connections

Portable 500 bar high flow Air Driven Hydraulic Test Pump
with a weight of only 20 Kg.

Ratio 1:60
Maximum Output Pressure: 500 bar (7,200 psi)
Maximum Flow: 11 L/min (2.90 gpm)
Maximum Air Supply: 12 bar (170 psi)
Maximum Air Consumption: 3.1 Nm3/min (110 scfm)
Working Temperature: 5-60 degree Celcius (41-140 degree Fahrenheit)

The unit is a ready to use pump and includes the following components:
-0-600 bar (0-9,000 psi) hydraulic gauge for pressure indication.
-0-8 bar 1/2" Air Filter/Regulator and a 1/2" Lubricator.
-Ball Valve in the air supply to be use as a start/stop valve.
-Geka fluid supply connection with a 1/2" NPT strainer.
-1/2" NPT female high pressure outlet.
-1/2" Needle valve to be used as a Bleed Valve.

High Pressure connection: 1/2"NPT female
Fluid Supply connection: GEKA
Air Supply connection: 1/2" BSP female
Bleed Valve: 1/2" NPT female

Standard compatible with the following fluids:
-Plain water
-Water / glycal mix
-Petroleum based oils

Portable Vacuum Pump
with a weight of only 11 Kg.

The Vacuum pump can be used to fill Test Opjects that are hard to fill due to their design, the Vacuum Pump ables you to quickly fill the object to 95%.

Maximum Vacuum: 95% (-95 kPa)
Maximum Flow: 1650 L/min
Minimum Air Supply: 7 bar (100 psi)
MAximum Air Supply: 12 bar (170 psi)
Maximum Air Consumption: 810 NL/min
Working Temperature: 5-60 degree Celcius (41-140 degree Fahrenheit)

The unit is a ready to use and includes the following components:
-Ball Valve in the air supply to be use as a start/stop valve.
-Ø100mm. Vacuum Gauge for vacuum indication.
-0-8 bar 3/8" Air Filter/Regulator ( Preset at the most optimal setting ).

Vacuum connection: 1/2" BSP female
Air Supply connection: 1/2" BSP female

Pressure Relief Valve - Low Pressure

Pressure Connection : 1/4" NPT Male
Outlet Connection : 1/4" NPT Female

Pressure Range :
- 10 - 255 PSI
- 0,7 - 15,5 bar

Maximum cold working pressure Relief Valve Body : 300 psi / 20,7 bar
Material Relief Valve Body : Stainless Steel AISI 316
Material Seal - Relief Valve : FKM
